Description
controller only ~ power supply, LEDs and all other accessories are sold separately
Description
The PIXEL-REPEATER is an RS485 to SPI converter designed for digital, programmable, and addressable LED strips. It receives the RS485 bus signal from the RUNNING-LIGHT-CASAMBI controller and converts it into SPI control, enabling pixel-to-pixel LED management. This solution allows synchronized, long-distance control of digital LED strips from a single controller, eliminating the need for multiple RUNNING-LIGHT units.
This RS485 to SPI repeater supports RGB, RGBW, and Tunable White (TW) digital LED strip lights operating on constant voltage. It is powered by a SELV constant voltage supply ranging from 5 Vdc to 48 Vdc, including 5V, 12V, 24V, and 48V systems. The output voltage matches the input voltage, ensuring stable and consistent performance across various LED strip configurations.
The PIXEL-REPEATER enables reliable remote control via the BUS interface of the RUNNING-LIGHT-CASAMBI controller. It can duplicate dynamic lighting effects and transmit control signals to pixel LED strips installed up to 250 meters away, making it ideal for large-scale architectural, commercial, and lighting installations requiring extended distance communication.
With a maximum output current of 7A, the PIXEL-REPEATER delivers dependable power handling for demanding digital LED applications. Built-in protections include over-voltage protection, under-voltage protection, reverse polarity protection, and input fuse protection to safeguard both the device and connected LED strips.
General specifications
- Model: PIXEL-REPEATER
- Voltage Range: 5–48V DC
- Working temperature range: -10/+60°C (14 ~ 140°F)
- Maximum total current: 7A
- BUS type: RS485
- Maximum wiring distance: 250m
- Protection rating: IP20
- Dimensions: 71.7 x 21 x 15.5mm (2.82” × 0.83” × 0.61”)
- Warranty: 5 years
Downloads
- PIXEL-REPEATER cut sheet
Important Notes
- Items in stock are shipped the same day from Knoxville, Tennessee, United States
- Bulk pricing is available on request
